Custom size, length, and wall thickness available.
OEM logo printing and private label packaging supported.
Various coupling materials: stainless steel, PP, or brass.
Optional food-grade hose fittings and clamps.
MOQ: 1000 meters
Packing: Woven bag / Carton / Customized food-grade packaging
Delivery Time: 15–25 days after deposit
Payment Terms: T/T, L/C
Export Markets: Europe, Middle East, Southeast Asia, North America
Categories: PVC Lay Flat Hose
The Food Grade PVC Layflat Hose is designed for hygienic liquid transfer in food and beverage industries. Manufactured with FDA-approved, phthalate-free PVC material, it ensures safety and purity when conveying milk, beverages, distilled liquor, beer, jam, and other edible liquids. The hose features high flexibility, lightweight construction, and excellent pressure resistance, making it ideal for food processing, breweries, and dairy farms. Tested and certified to meet FDA and REACH (SGS) standards, this hose guarantees reliability and hygiene in every flow.
● FDA-approved, phthalate-free, and SGS REACH compliant.
● Non-toxic, odorless, safe for food-grade liquid transfer.
● Lightweight, flexible, and resistant to high pressure.
● Excellent resistance to acid, alkali, aging, and stretching.
● Smooth inner surface ensures easy cleaning and stable flow.
● Working temperature: -5℃ to +65℃.
● Suitable for conveying milk, beverage, distilled liquor, beer, jam, and other foods.
| Item | Specification |
| Material | Food-grade PVC (Phthalate-free, FDA compliant) |
| Size Range | 1” – 16” (25mm – 406mm) |
| Working Pressure | 2 – 8 bar |
| Burst Pressure | 6 – 24 bar |
| Working Temperature | -5℃ to +65℃ |
| Color | Transparent / Milky White / Custom |
| Certification | FDA, REACH (SGS) |
| Application | Conveying milk, beverage, distilled liquor, beer, jam, and other foods |
| Specification: | |||||||||||
| INNER DIAMETER | THICKNESS | OUTER DIAMATER | WORKING PRESSURE | BURST PRESSURE | WEIGHT | ROLL | COMPLIANCE | HS CODE | |||
| INCH | MM | MM | MM | BAR | PSI | BAR | PSI | G/M | M | ||
| 1″ | 25 | 1.3 | 27.6 | 4 | 60 | 15 | 220 | 150 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 1-1/4″ | 32 | 1.2 | 34.4 | 4 | 60 | 15 | 220 | 170 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 1-1/2″ | 38 | 1.2 | 40.4 | 4 | 60 | 15 | 220 | 190 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 2″ | 51 | 1 | 53 | 4 | 60 | 12 | 180 | 220 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 2-1/2″ | 64 | 1.1 | 66.2 | 4 | 60 | 12 | 180 | 300 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 3″ | 76 | 1.1 | 78.2 | 4 | 60 | 12 | 180 | 360 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 4″ | 103 | 1.25 | 105.5 | 4 | 60 | 12 | 180 | 550 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 5″ | 127 | 1.35 | 129.7 | 3.5 | 51 | 10 | 150 | 750 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 6″ | 153 | 1.35 | 155.7 | 3 | 45 | 9 | 270 | 900 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 8″ | 203 | 2 | 207 | 3 | 45 | 9 | 135 | 1600 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 10″ | 255 | 2.4 | 259.8 | 2.5 | 36 | 7 | 101 | 2600 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 12″ | 307 | 2.5 | 312 | 2 | 30 | 6 | 90 | 3000 | 100 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 14″ | 358 | 3 | 364 | 2 | 30 | 6 | 90 | 5000 | 50 | REACH/FDA/EU FOOD GRADE | 39173900 |
| 16″ | 408 | 3 | 414 | 2 | 30 | 6 | 90 | 6000 | 50 | REACH/FDA/EU FOOD GRADE | 39173900 |
