Weifang Raleon Plastic Co., Ltd.
✔ Custom sizes (diameter & length)
✔ Color customization (e.g., blue, transparent, or others)
✔ Logo printing and packaging options available
✔ High or low-pressure ratings: 4bar, 5bar, 6bar
✔ OEM & ODM support
MOQ: 1000 meters (negotiable)
Payment Terms: T/T, L/C, Western Union
Delivery Time: 10–25 days after deposit
Port of Loading: Qingdao / Shanghai / Ningbo
Sample: Available upon request
Daily Output: 10,000 meters/day
Categories: PVC Steel Wire Hose
The Light Duty PVC Steel Wire Reinforced Hose is designed for flexible use in a wide range of applications, such as water, oil, and powder transfer in factories, agriculture, and other industries. It features a spiral steel wire reinforcement incorporated within the PVC tubing, ensuring strength, durability, and flexibility. This hose is non-toxic, lightweight, and UV-resistant, making it ideal for environments with moderate pressure.
The smooth surface and high-quality material offer excellent performance for water and oil conveying, with high abrasion, acid, alkali, and aging resistance. Its environmental-grade composition meets REACH standards, ensuring safety and eco-friendliness.
● Non-toxic, lightweight, and odorless
● UV-resistant for long-term outdoor use
● High abrasion resistance, acid & alkali resistance
● Flexible and smooth surface for easy handling
● Ideal for low-pressure applications
● Working Temperature: -5°C to +65°C
| Specification: | ||||||||||
| INNER DIAMETER | THICKNESS | OUTER DIAMATER | WORKING PRESSURE | BURST PRESSURE | WEIGHT | ROLL | HS CODE | |||
| INCH | MM | MM | MM | BAR | PSI | BAR | PSI | G/M | M | |
| 3/8″ | 9 | 2.5 | 14 | 6 | 90 | 18 | 270 | 150 | 100 | 39173900 |
| 3/8″ | 10 | 2.5 | 15 | 6 | 90 | 18 | 270 | 160 | 100 | 39173900 |
| 1/2″ | 12 | 2.5 | 17 | 6 | 90 | 18 | 270 | 170 | 100 | 39173900 |
| 5/8″ | 15 | 3 | 21 | 6 | 90 | 18 | 270 | 250 | 100 | 39173900 |
| 3/4″ | 19 | 2.5 | 24 | 5 | 70 | 15 | 210 | 250 | 50 | 39173900 |
| 1″ | 25 | 2 | 29 | 5 | 70 | 15 | 210 | 220 | 50 | 39173900 |
| 1″ | 25 | 2.5 | 30 | 4 | 60 | 12 | 180 | 350 | 50 | 39173900 |
| 1-1/4″ | 32 | 2 | 36 | 4 | 60 | 12 | 180 | 400 | 50 | 39173900 |
| 1-1/4″ | 32 | 3 | 38 | 3 | 50 | 10 | 150 | 500 | 50 | 39173900 |
| 1-1/4″ | 32 | 3.5 | 39 | 3 | 50 | 10 | 150 | 600 | 50 | 39173900 |
| 1-1/2″ | 38 | 2 | 42 | 3 | 50 | 9 | 150 | 500 | 50 | 39173900 |
| 1-1/2″ | 38 | 3 | 44 | 3 | 50 | 9 | 150 | 600 | 50 | 39173900 |
| 1-3/4″ | 45 | 2.5 | 50 | 3 | 50 | 9 | 150 | 800 | 50 | 39173900 |
| 1-3/4″ | 45 | 3.5 | 52 | 3 | 50 | 9 | 150 | 600 | 50 | 39173900 |
| 1-7/8″ | 48 | 3 | 54 | 3 | 50 | 9 | 150 | 800 | 50 | 39173900 |
| 1-7/8″ | 48 | 4 | 56 | 3 | 50 | 9 | 150 | 1000 | 50 | 39173900 |
| 2″ | 50 | 2.75 | 55.5 | 3 | 50 | 9 | 150 | 800 | 50 | 39173900 |
| 2″ | 50 | 3.5 | 57 | 3 | 50 | 9 | 150 | 1000 | 50 | 39173900 |
| 2″ | 50 | 5 | 60 | 3 | 50 | 9 | 150 | 1400 | 50 | 39173900 |
| 2-5/16″ | 58 | 3.5 | 65 | 2 | 30 | 6 | 90 | 1200 | 30 | 39173900 |
| 2-1/2″ | 64 | 4 | 72 | 2 | 30 | 6 | 90 | 1500 | 30 | 39173900 |
| 2-1/2″ | 64 | 5.5 | 75 | 2 | 30 | 6 | 90 | 2000 | 30 | 39173900 |
| 3″ | 76 | 4 | 84 | 2 | 30 | 6 | 90 | 1600 | 30 | 39173900 |
| 3″ | 76 | 5.5 | 87 | 2 | 30 | 6 | 90 | 2500 | 30 | 39173900 |
| 3-1/2″ | 90 | 6 | 102 | 2 | 30 | 6 | 90 | 3000 | 20 | 39173900 |
| 4″ | 102 | 5 | 112 | 2 | 30 | 6 | 90 | 2800 | 20 | 39173900 |
| 4″ | 102 | 5.5 | 113 | 2 | 30 | 6 | 90 | 3000 | 20 | 39173900 |
